Description
Specifications:
Applications: Filtration (1 to 6 funnels), Aspiration, Desiccation, SPE, Replace water aspirator, Vacuum Drying
Type: Laboratory Vacuum Pump
Free Air Displacement cfm (l/min.) @60Hz: 1.6(45)
Free Air Displacement m3/hr (l/min.) @50Hz: 2.3(38)
Ultimate Pressure: 60(80)
Maximum Vacuum: 27.6
Max Pressure PSIG (pascal): 100(106)
Motor Horsepower (watts):1/4(190)
Adjustable Vac. / Gas Ballast: Yes
Tubing Needed: 3/16(5)
Intake Thread NPT: 1/4
Overall Dimensions LxWxH in. (cm): 10×7.5×9 (25.4×19.1×7.7)
Intake Catch Jar: Yes
Exhaust Catch Jar: Yes
Adjustable Vacuum: Knob
Adjustable Pressure: Yes
Vacuum Gauge: Dial
Pressure Gauge: Dial
