Description
Specifications:
Sample capacity: 96 × 0.2 mL PCR tubes or 1 x 96-well PCR plate (8 × 12)
Temp. control range of the block: 4 – 99 °C
Temp. control mode: Fast, Standard, Safe
Heating technology of the block: Peltier elements, Triple Circuit Technology
Gradient range: 1 – 20 °C
Gradient temperature range: 30 – 99 °C
Lid temperature range: 37 – 110 °C
Block homogeneity: 20–72 °C ±0.3 degree Celsius
Block temperature accuracy: ±0.2 degree Celsius
Block homogeneity: 90 °C ±0.4 degree Celsius
Heating rate: 4 °C/s 1
Cooling rate: 3 °C/s 1
Gradient block: Over 12 rows
Interfaces: 1 × Centronics, 1 × RS-232,
Total weight: 18.5 kilogram (40.8 lbs)
Power supply: 110 V or 230 V, 50 – 60 Hz
Max. power consumption: 950 watt
Dimensions (W × D × H): 26 × 41.5 × 37 cm
Thermoblock: Aluminum
