Description
Unit includes:
– AU 480 main unit
– Onboard refrigerated reagent compartment
– Operating software and accessories
Put the power of versatility to work for your lab with a smart and efficient clinical chemistry analyzer solution. The AU480 chemistry analyzer is the ideal primary clinical chemistry analyzer for low- to mid-volume hospitals and laboratories, or dedicated specialty chemistry or STAT analyzer for larger laboratories. With throughput of up to 400 photometric tests per hour (up to 800 with ISEs), increased onboard testing, reduced sample volume and easy operation, the AU480 delivers efficiency for laboratories around the world.
Key Specifications:
Simultaneously Processed Analytes: 60 photometric + 3 ISE; 120 pre-programmed onboard tests
Throughput: 400 photometric tests/hour; up to 800 with ISE
ISE Throughput: 200 samples/hour; up to 600 tests/hour (ISE only)
Sample Capacity: 80 samples (racks of 10)
STAT Sample Positions: Up to 22
Sample Volume: 1–25 μl (0.1 μl steps)
Reagent Capacity: 76 positions
Reagent Bottle Sizes: 15 ml, 30 ml, 60 ml
Reagent Storage Temperature: 4–12°C
Reagent Volume (R1 & R2): 10–250 μl (1 μl increments)
Total Reaction Volume: 90–350 μl
Reaction Time: Up to 8 min 37.5 sec
Incubation Temperature: 37°C (dry bath)
Optical Density Range: 0–3.0 OD
Wavelengths Available: 13 (between 340–800 nm)
Sample Pre-dilution Ratios: 3, 5, 10, 15, 20, 25, 50, 76, 100
Data Storage Capacity: 100,000 samples; 200,000 reaction tests
