Description
The NEW super compact and intuitive live cell imaging system, Celloger Nano – got everything you need to perform your sophisticate laboratory works. Equipped with exceptional fluorescence and auto-focusing technology, precise stage controller, and user-friendly software, accelerates your cell-based research works. Expand your cell-based research through our multifunction live cell imaging system, Celloger Nano.
Description:
One color fluorescence (GFP or RFP) and brightfield imaging technology
Compact size that easily fits into standard CO2 incubators
High quality system yet cost-effective
Compatible with various cell and tissue culture vessel types
Intuitive UI/UX and easy to acquire confluency data
Increased focus speed and reproducibility with reliable autofocusing function
Movie maker provides one-click easy way to make a time-lapse video
Specifications:
Dimensions: 211*146*188mm
Weight: 3.2kg (2.7kg / No Stage)
Objective Lens: 2X / 4X / 10X
Camera: 1.25MP / 5MP CMOS
Stage: Manual xy stage
Operating environment: 5-40℃, 20-95% humidity
File export format: TIFF, JPEG, PNG, AVI
Resolution: 1296 x 972 pixel (1.25MP) / 2592 x 1944 pixel (5MP)
Imaging positions: Single
Imaging mode: Bright-field / GFP / RFP
Vessel holders: Well plate(6-96), Petri dish(35-100), T-flask(25-75)
Application:
Wound healing assay
Cell migration
Cell morphology
Cell confluency
Cell proliferation
Cytotoxicity assay
Transfection efficiency assessment
Coculture monitoring
