Description
Specifications:
• Display unit: Liquid Crystal Display with two rows of sixteen digits
• Keyboard: Four key membrane keyboard
• Number of dispensing channels: 1-, 2- or 4-channels
• Manifold types: 8- or 16-way for parallel processing of 8- or 16-wells, 8- or 16-way Process control manifold
• Volume of solution dispensed:
o 50 – 3000 μl in 50 μl steps for washing
o 50 – 400 μl in 50 μl steps for dispensing
• Dispensing accuracy: <= 2 % (300μl dispense volume of wash-buffer, dispense rate: 3, 8-way manifold, Greiner 96-well flat bottom plate).
• Dispensing uniformity: CV: <= 4% over the plate (300μl dispense volume of wash-buffer, dispense rate: 3, 8-way manifold, Greiner 96-well flat bottom plate).
• Residual volume: Crosswise aspiration: <= 2 μl per well for 96-well flat bottom Greiner plate (asp. rate 3, asp. time 4 sec., head speed 10mm/sec, 8-way manifold, wash buffer in all wells)
• Interface: USB
• Shaking: Linear shaking; high-, medium- and low-setting
• Outside dimensions for plate washing: Width: 27.5 cm, Depth: 36.6 cm, Height: 18.1 cm
• Weight: 6.6 kg
