Description
Andor’s Zyla sCMOS camera platform offers high speed, high sensitivity and high resolution imaging performance. The remarkably light and compact, thermoelectrically-cooled design, integrates perfectly into both laboratory and OEM applications alike. Zyla is ideally suited to many cutting-edge experiments that push the boundaries of speed and sensitivity. The unprecedented value and flexibility of the Zyla means it is also redefining the concept of a ‘workhorse’ camera, rapidly displacing interline CCDs as the gold standard microscope detector.
Specifications:
Sensor Type: Front Illuminated Scientific CMOS
Active Pixels: 2560 x 2160 (5.5 Megapixel)
Sensor Size: 16.6 x 14.0 mm (21.8 mm diagonal)
Pixel Readout Rate (MHz): 200 (100 MHz x 2 sensor halves). 560 (280 MHz x 2 sensor halves)
Read Noise (e-):
Rolling Shutter: 200 MHz 0.9 [1.2], 560 MHz 1.2[1.6]
Global Shutter: 200 MHz 2.3[2.5], 560 MHz 2.4[2.6]
Maximum Quantum Efficiency •3: 60%
Sensor Operating Temperature:
Air Cooled: 0ºC (up to 30ºC ambient)
Dark Current, e-/pixel/sec @ min temp •4:
Air Cooled: 0.10
Readout Modes: Rolling Shutter and Global Shutter (Snapshot)
Maximum Dynamic Range: 33,000:1
Photon Response Non-Uniformity (PRNU):
Half-light Range: < 0.01%
Low-light Range: <0.1%
Pre-defined Region of Interest: 2048 x 2048, 1920 x 1080, 1392 x 1040, 512 x 512, 128 x 128
User Defined ROI (Granularity): Yes (1 pixel) **
Pixel Size (W x H): 6.5 μm
Pixel Well Depth (e-): 30,000
Linearity (%, maximum) •5
Full-light Range: Better than 99.8%
Low-light Range (< 1000 electrons signal): Better than 99.9%
MTF (Nyquist @ 555 nm): 45%
Anti-blooming Factor: x 10,000
Hardware Timestamp Accuracy: 25 ns
Internal Memory: 1 GB
