Description
Specifications:
- Model: 48R
- Throughput: 48
- Fluorescence Channels: 2
- Compatible Fluorophores: (Channel 1: FAM, SYBR Green I, etc.) and (Channel 2: VIC, HEX, TET, JOE, etc.)
- Light Source: High-brightness, long-life and maintenance-free LED light source
- Detector: Photodiodes (PDs)
- Fluorescence Scanning Time: 48-well 2-channel detection completed within 2s
- Heating Rate: Maximum heating ramp rate ≥8.0℃/s; Average heating ramp rate ≤6.2℃/s
- Cooling Rate: Maximum cooling ramp rate ≥6.2℃/s; Average heating ramp rate≥4.5℃/s
- Temperature Accuracy: ≤ 0.1℃
- Special Temperature Setting Function: Support thermal gradients PCR, long PCR, Touch Down PCR
- Suitable Consumables: 0.2ml clear non-skirt 48-well plates, 8-tube strips, single tubes, etc.
- Sample Testing linearity: linear Correlation: CV≥0.999
- Repeatability: cycle threshold (Ct) value CV ≤0.5%
- Operating System: Windows XP Pro or higher
- Power Supply and Power Consumption: AC 100-240V, 50-60Hz; 600VA
- Weight: 11Kg (net)
- Instrument Dimension: 260x400x260mm
