Description
Features:
- LED digital display for easy reading
- Hot surface warning to prevent burns
- High safety and strong stirring performance
- 3D digital wheel adjustment of speed and temperature
- Brushless DC motor is maintenance free and explosion proof
- Temperature is up to 280°C and the safety temperature is 50-320°C
- Double internal temperature sensor PT1000 and one external PT1000
- Enclosed heating plate design reduces the risk of liquid splashing into the equipment
- Optimized PID program control provides extremely high accuracy of temperature and speed
- Automatically identifies temperature sensor PT1000 and transfer to PT1000 operation mode
- Stainless Steel with ceramic coated heating plate allows for optimum heat transfer and easy to clean
Specifications:
- Model: MI0102003
- Stirring position: 1
- Set-up plate dimensions: Ø 137 mm
- Set-up plate material: Stainless steel with ceramic coated
- Motor type: DC motor
- Max. stirring quantity [H2O]: 5L
- Max. stirring bar [L x Φ]: 55*10 mm
- Motor rating output: 1.4W
- Speed range[rpm]: 100-1500
- Speed display: LED
- Heating output: 600W
- Heating temperature range: Room temperature – 280°C
- Temperature display: LED
- Temperature display resolution: 0.1
- Safety temperature: 50-320°C
- External temperature sensor: Optional
- Temperature control accuracy with external temperature sensor: ±1
- Hot surface warning: 50°C
- Permissible ambient temperature: 5 – 40°C
- Permissible relative humidity: 80%
- Protection class according to DIN EN 60529: IP 42
- Voltage [VAC]: 200-240/100-120
- Frequency: 50/60 Hz
- Power: 630W
- Dimensions [W x D x H, mm]: 268 x 160 x 85
- Weight: 1.8kg
