Description
Features:
- Compact, Lightweight and Sleek design
- Provides constant speed even with changes in viscosities of the sample
- Wide LED display for precise speed adjustment and monitoring
- LED display shows actual and set speeds alternately
- Overload protection system if the torque exceeds the stirrer ratings
- Safety circuits: Circuit auto cut-off feature for additional protection
- Maintenance-free Brushless DC motor
- The through-shaft housing design allows for easy impeller height adjustments and thereby less downtime in between sample changes less downtime in between sample changes
Specifications:
- Model: OHS-60D
- Voltage [V]: 100 V-240V
- Frequency [Hz]: 50/60
- Max. input power: 160W
- Speed range under nominal load [rpm]: 0/50-2000
- Speed increment [rpm]: Stepless, 10rpm
- Speed accuracy: ±1%
- Max. torque at stirrer shaft [N.cm]: 60
- Max. stirring quantity (H2O): 60L
- Max. Viscosity [mPas]: 50,000(2000rpm) and 100,000(1000rpm)
- Speed display: LED
- Protection class according to DIN EN 60529: IP42
- Protection at overload: Yes
- Motor protection: Yes
- Over temperature protection: Yes
- Permissible ambient temperature: 5-40°C
- Permissible relative humidity: 80%
- Clamping chuck-clamping range: 0.5-10mm
- Dimensions (WxDxH) (without extension arm) [mm]: 71x174x240
- Weight (with extension arm and clamping chuck) [kg]: 2.5 kg
