Description
Recirculating Chiller RC03 provides an economic and environmentally friendly cooling solution for many laboratory applications. With intelligent PID control, the device achieves excellent temperature stability and is suitable for a wide range of applications including cooling of rotary evaporators, reactor blocks, vapor barriers, or heat exchangers.
Features:
- Compact design suitable for laboratory benches and fume hoods
- Maintenance-free pressure/suction pump, suitable for both open and closed loop application
- Splash-proof keypad, large LED display
- PID control and advance proportional cooling provides excellent temperature stability.
- Stainless steel water bath with easily visible level indicator
- Convenient liquid filling and draining, and overflow port protection on the tank.
- Pump pressure and pump flow can automatically adapt to the external load.
- High pressure and over-current protection on the cooling system to avoid compressor overload
- Uses Environmental-friendly refrigerant
- Visual and Audio Alarms
Specifications:
- Working temperature range [°C]: -20…RT
- Temperature stability DIN 12876 [±K]: ±0.3
- Temperature display: LED
- Cooling capacity (at 20 °C): 450W
- Pump type: Pressure/ suction pump
- Pump capacity adjustable: no
- Pump pressure max. [bar]: 0.2
- Pressure suction max. [bar]: 0.1
- Pump pressure max. [L/min]: 12
- Pump connection [mm]: ID.=8
- Bath volume: 3L
- Dimension(WxDxH) [mm]: 220x420x495
- Display resolution: 0.1°C
- Permissible ambient temperature: 5 ~ 32°C
- Permissible relative humidity: 80%
- Weight: 23kg
- Power supply: 220 V/110 V; 50 Hz/60 Hz
