Description
Features:
- Error code display
- Fixed safety circuit
- LED display for easy reading
- Adjustable temperature is up to 150°C
- Various applications with different blocks
- High temperature stability is up to ± 0.2°C
- Adjustable timing range of 1min to 99h59min
- 3D digital wheel adjustment of time and temperature
- Automatic calibration with external PT1000 temperature sensor
- Machined aluminum heating unit allows for highly precise control of temperature
- Included PT1000 temperature sensor allows temperature control directly in the sample vessel
Specifications:
- Model: TC0401001
- Number of blocks: 1
- Heat output: 165 W
- Heating temperature range: RT+5°C to 150°C
- Temperature display: LED
- Adjustment and display resolution: 0.1K
- Temperature stability within the blocks at 37°C: ±0.5°C
- Temperature stability within the blocks at 60°C: ±0.5°C
- Temperature uniformity at 37°C: ±0.5°C
- Set-up plate material: Aluminium alloy
- Set-up plate dimensions: 96x76mm
- Fixed safety circuit: 180°C
- Timer: √
- Time setting range: 1min – 99Hr 59min
- Dimensions (W x H x D): 152 x 86 x 190mm
- Weight: 1.5kg
- Permissible ambient temperature: 5 – 40 °C
- Permissible relative humidity: 80%
- Protection class according to DIN EN 60529: IP 21
- Voltage: 200-240/115
- Frequency: 50/60 Hz
