Description
Features:
- Accurate Temperature control and excellent mixing performance
- Microprocessor control ensures superior temperature stability and uniformity
- Programmable Heating, Cooling, and Mixing Sequences
- Large LCD touchscreen for intuitive navigation and programming
- Durable, low-noise Brushless DC motor
- Interchangeable modules with automatic detection function
- Auto resumption after power failure
- Comes with a standard block module (block for 24 x 1.5mL tubes)
Specifications:
- Name: Heat Cool Thermo Mixer
- Model: TMX100C
- Type: Heating/Cooling/Mixing
- Speed Range: 250 to 3000rpm
- Mixing Orbit (Diameter): 3.0mm
- Temperature Control Range: Ambient-15°C to 100°C
- Recommended Ambient Temperature: 10°C to 30°C
- Temperature Setting Range: 0°C to 100°C
- Display: 7-inch Color Touchscreen
- Sample Capacity: 0.1ml to 50ml
- Standard Module: 1.5ml x 24-Well Plate
- Temperature Accuracy: (±0.2°C at 20–40°C) (±0.5°C at<20°C or >40°C)
- Temperature Uniformity: ±0.5°C
- Temperature Stability: ±0.5°C
- Temperature Resolution: 0.1°C
- Heating Rate (4 options): Full Power, 5°C/min., 2°C/min., 1°C/min.
- Cooling Rate (4 options): Full Power, 2°C/min., 1°C/min., 0.5°C/min.
- Programs: Programmable up to 5 Steps
- Cycle Times: Up to 999 times
- Calibration: 4 Calibration Points (10°C/40°C/70°C/95°C)
- Timer: 0-99hr 59min 59s
- Additional Features: Pre-Heating, Power Failure Recovery
- Output: 300W (max.)
- Power Supply: 110-220V AC, 50Hz/60Hz
- Weight (including standard module): <10kg
- Dimension (L x W x H): 332 x 227 x 185mm (including standard module, without lid)
