Description
HelixDrive is an ultra-compact, oil-free dry screw vacuum pump. Its unique coaxial design, with an integrated motor, enhances both efficiency and reliability. Its proprietary coating protects the pump from the most demanding industrial applications. Ideal for harsh applications where oil is not tolerated.
Compact Design
As one of the most innovative designs, this dry screw pump delivers fast pumping speed in an ultra-compact package.
Oil-Free Operation
Ideal for harsh applications where oil is not tolerated.
Temperature Management
Our temperature management system is optimized for the most effective cooling. Our larger pumps are water-cooled to enhance the performance of the pump, while our smaller pumps are air-cooled for easy operation.
Technical Specification
Pumping speed (60Hz): 100 m³/h
Ultimate Pressure: 3.0×10⁻² mbar (2.2×10⁻² Torr)
Gas Purge Dry Nitrogen / Dry Compressed Air: 0–60 slm
Gas Purge Pressure: 0.15–0.2 MPa
Gas Purge Joint: Quick joint for air pipe Φ6mm
Power Rating: 3 kW
Current at Ultimate Pressure: 4 A
Peak Current: 7 A
PID Functions: Yes
Analog Input: Yes
Communication Function: MODBUS-RTU
Inlet/Outlet: KF40
Water Vapor Treatment Capacity: 800 g/h
Cooling Mode: Water Cooling
Noise Level: ≤60 dB
Weight: 205 kg (452 lbs)
Dimensions (L×W×H): 899.2 × 464.8 × 548.6 mm (35.4 × 18.3 × 21.6 in)
